ProMini is a versatile, all-electric automatic screen-printing press built for shops that need reliable performance in a smaller footprint. Operating without an air compressor, it offers quiet, low-maintenance production with minimal power draw and fast setup.
Ideal for promotional products and small-format jobs, the ProMini delivers professional-level quality and efficiency in a compact, easy-to-run platform.
.svg)
Specifications
PRO MINI 8/1
PRO MINI 8/2
PRO MINI 8/3
PRO MINI 10/4
Electrical Requirements1,2
208 230 V, 1 ph, 39 A,50/60 Hz, 7.05 kW (UL)208 230 V, 1 ph, 39 A,50 Hz, 7.05 kW (CE)
208 230 V, 1 ph, 39.5 A,50/60 Hz, 7.15 kW (UL)208 230 V, 1 ph, 39.5 A,50 Hz, 7.15 kW (CE
208 230 V, 1 ph, 40 A,50/60 Hz, 7.25 kW (UL)208 230 V, 1 ph, 40 A,50 Hz, 7.25 kW (CE)
208 230 V, 1 ph, 53 A,50/60 Hz, 9.6 kW
In built Flash Cure Units
3
3
3
4
Diameter
128 cm (50.5")
128 cm (50.5")
128 cm (50.5")
146 cm (57.5")
Maximum Frame Size
28 × 38 cm (11" x 15")
28 × 38 cm (11" x 15")
28 × 38 cm (11" x 15")
28 × 38 cm (11" x 15")
Maximum Image Area
15 × 15 cm (6" x 6")
15 × 15 cm (6" x 6")
15 × 15 cm (6" x 6")
15 × 15 cm (6" x 6")
Machine Weight
262 kg (578 lb)
294 kg (648 lb)
326 kg (719 lb)
400 kg (882 lb)
Standard Pallet Size
11 x 23 cm (4.3" x 9")
11 x 23 cm (4.3" x 9")
11 x 23 cm (4.3" x 9")
11 × 23 cm (4.3" x 9")
Stations/Colors
8/1
8/2
8/3
10/4
1General usage may vary, but will be significantly less than stated values
2Use Servo Stabilizers to safeguard the machine from Voltage Fluctuation out of the main supply.
