Vortex
Applications
Overview
Specification
An Advanced Industrial
textile conveyor dryer for all your
large-scale curing needs.
Vortex is a high-performance industrial textile dryer built for large-scale printing. With modular expansion, energy-efficient air-handling, and Cool-Skin technology, it offers up to 90% air recirculation while keeping the exterior cool. Available in gas and electric variants, it ensures reliable, low-maintenance curing for plastisol, water-based, and DTG inks.
Advanced Air Handling Technology
Smart Control Center
Easy Maintenance
Sturdy Construction & Design
.svg)
Multipe Variants
Electric Cal-Rod Heaters
German Make Gas Burner
Air Knives Channels
Technical specifications
Specifications
Vortex Gas 60/10
Vortex Gas 60/14
Vortex Gas 60/18
Vortex Gas 60/22
Belt Width
152.4 cm (60")
152.4 cm (60")
152.4 cm (60")
152.4 cm (60")
Burner Input Maximum
320000 Btu
320000 Btu
320000 Btu
320000 Btu
Gas Input Size
19.5 mm (3/4")
19.5 mm (3/4")
19.5 mm (3/4")
19.5 mm (3/4")
Average Gas (LPG) Consumption1
2.0 kg/hr
2.0 kg/hr
2.4 kg/hr
2.4 kg/hr
Rated Electrical Requirements2,3
208-230 V, 3ph, 14.5 A, 60 Hz, 4.7 kW 380-415 V, 3ph, 8.5 A, 50 Hz, 4.7 kW
208-230 V, 3ph, 14.5 A, 60 Hz, 4.7 kW 380-415 V, 3ph, 8.5 A, 50 Hz, 4.7 kW
208-230 V, 3ph, 14.5 A, 60 Hz, 4.7 kW 380-415 V, 3ph, 8.5 A, 50 Hz, 4.7 kW
208-230 V, 3ph, 14.5 A, 60 Hz, 4.7 kW 380-415 V, 3ph, 8.5 A, 50 Hz, 4.7 kW
Exhaust Blower System
14.8cm (5.8") : 7360 L/min (260 cfm)
14.8cm (5.8") : 7360 L/min (260 cfm)
14.8cm (5.8") : 7360 L/min (260 cfm)
14.8cm (5.8") : 7360 L/min (260 cfm)
Heat Chamber Length
305 cm (10')
427 cm (14')
549 cm (18')
670 cm (22')
Overal Dimensions (L x W x H)
805cm (317") x 237cm (93.2") x 197cm (77.5")
927cm (365") x 237cm (93.2") x 197cm (77.5")
1050cm (413") x 237cm (93.2") x 197cm (77.5")
1170cm (461") x 237cm (93.2") x 197cm (77.5")
Total Machine Weight
1970 kg (4343 lbs)
2460 kg (5423 lbs)
2930 kg (6460 lbs)
3380 kg (7496 lbs)
Standard Infeed Length
250cm (98.5")
250cm (98.5")
250cm (98.5")
250cm (98.5")
Standard Outfeed Length
250cm (98.5")
250cm (98.5")
250cm (98.5")
250cm (98.5")
1Values derived as average consumption after testing at 180 degree C, 60s Dwell Time and Exhaust as per factory setting. The values can vary with different environmental factors, ink & fabrics used.
2General usage may vary, but will be significantly less than stated values.
3Use Servo Stabilizers to safeguard the machine from Voltage Fluctuation out of the main supply.
DOWNLOAD PDF
Specifications
Vortex Electric 60/10
Vortex Electric 60/14
Vortex Electric 60/18
Vortex Electric 60/22
Belt Width
152.4 cm (60")
152.4 cm (60")
152.4 cm (60")
152.4 cm (60")
Average Electrical Consumption1
28 kW/hr
31 kW/hr
34 kW/hr
38 kW/hr
Rated Electrical Requirements (Electric)2
208-230 V, 3ph, 97 A, 60 Hz, 35.5 kW 380-415 V, 3ph, 56 A, 50 Hz, 35.5 kW
208-230 V, 3ph, 97 A, 60 Hz, 35.5 kW 380-415 V, 3ph, 56 A, 50 Hz, 35.5 kW
208-230 V, 3ph, 125A, 60 Hz, 46 kW 380-415 V, 3ph, 72A, 50 Hz, 46 kW
208-230 V, 3ph, 125A, 60 Hz, 46 kW 380-415 V, 3ph, 72A, 50 Hz, 46 kW
Exhaust Blower System
14.8 cm (5.8") : 7360 L/min (260 cfm)
14.8 cm (5.8") : 7360 L/min (260 cfm)
14.8 cm (5.8") : 7360 L/min (260 cfm)
14.8 cm (5.8") : 7360 L/min (260 cfm)
Heat Chamber Length
305 cm (10')
427 cm (14')
549 cm (18')
670 cm (22')
Overal Dimensions (L x W x H)
805cm (317") x 237cm (93.2") x 197cm (77.5")
927cm (365") x 237cm (93.2") x 197cm (77.5")
1050cm (413") x 237cm (93.2") x 197cm (77.5")
1170cm (461") x 237cm (93.2") x 197cm (77.5")
Total Machine Weight
1970 kg (4343 lbs)
2460 kg (5423 lbs)
2930 kg (6460 lbs)
3380 kg (7496 lbs)
Standard Infeed Length
250 cm (98.5")
250 cm (98.5")
250 cm (98.5")
250 cm (98.5")
Standard Outfeed Length
250 cm (98.5")
250 cm (98.5")
250 cm (98.5")
250 cm (98.5")
1Values derived as average consumption after testing at 180 degree C, 60s Dwell Time and Exhaust as per factory setting. The values can vary with different environmental factors, ink & fabrics used.
2General usage may vary, but will be significantly less than stated values.
