DGI FH 3204

FH 3204

Applications

Overview

Specification

Applications We Power

Fashion & Lifestyle

Home Furnishing

Soft Signage

Sportswear

Print Applications

Baby Garments

Socks

Tagless Neck Label

Swimming Cap

High-Versatility Printer: Fabric, Paper, and Mesh in One

This printer is engineered for maximum flexibility, allowing you to handle diverse media with a single machine. Equipped with 4 Kyocera Printheads and up to 6 color channels, it delivers precise results across a wide gamut, including fluorescent and light colors. With the added benefit of mesh printing and mobile monitoring, it's a powerful and adaptable tool for modern textile and soft signage applications.

4 Kyocera Printheads

Fabric & Paper in One Printer

Up to 6 Color Channels (Supports Fluorescent and Light Colors)

Mesh Printing Capability

Limited Coverage of 3 Years Warranty

Mobile Monitoring (Allows remote status check)

250

PRINTS PER HOUR

1

OPERATOR REQUIRED

CMYK + OG

Color Channels

2

In-Line PreTreat Stations for Light & Dark

36

Printheads

Technical specifications

Specifications

DGI FT 3204X

Print Speed (4 heads)

155m/hr (1,668ft), 95m/hr (1,022ft), 50m/hr (538ft), 35m/hr (377ft)

Print Resolution (4 heads)

600 x 600dpi (2Pass), 600 x 600dpi (4Pass), 600 x 1,200dpi (8Pass), 600 x 1,800dpi (12Pass)

Print Speed (2-3 heads)

85m/hr (914ft), 60m/hr (645ft), 45m/hr (484ft)

Print Resolution (2-3 heads)

600 x 600dpi (4Pass), 600 x 900dpi (6Pass), 600 x 1,200dpi (8Pass)

Max Print Width

3,200mm / 126 inch

Max Media Load

3,220mm / 300mm / 100kg (127 inch / 12 inch / 220lb)

Print Mode

Bi-Direction / Uni-Direction, Normal / Interleave

Printhead

TCP / IP, USB 3.0

Color

4 Colors (K, C, M, Y) / 6 Colors (Fy, Fp / Lm, Lc)

Ink

DGI original water-based Dye Sublimation Ink

Interface

TCP / IP, USB 3.0

Environmental Range

Temperature: 20~30°C (68~86°F), Humidity: 40~70% .Environment condition may affect on final printing quality.

Electricity Requirements

Single phase, 200-240V, 50/60 Hz, 35A (Printer: 5A, Dryer: 30A)

*All specifications are subject to change without prior notice
