Galaxy
Lunar
OverviewApplicationsSpecifications

Print Applications

Pocket T-shirt
Hand holding three ribbed socks in beige, white, and black, each featuring a black palm tree design and text.
Socks
Tagless Neck Label
Koozie
Golf Towel

Compact Design.
Proven Performance.

ProMini is a versatile, all-electric automatic screen-printing press built for shops that need reliable performance in a smaller footprint. Operating without an air compressor, it offers quiet, low-maintenance production with minimal power draw and fast setup.

Ideal for promotional products and small-format jobs, the ProMini delivers professional-level quality and efficiency in a compact, easy-to-run platform.

PNU Head lifting (Same as Rival)

Operating Panel (New)

HMI (Same as Rival)

Index & Skip Foot Pedal

Pneumatic Frame Locks

Squeegee Pressure Regulator

Front and Rear Micro Registration

Multi Print Mode Program

Print-Start / Print-Finish mode

Front to Back/Back to Front- Squeegee Mode

Maintenance Minder Program

Laser Registration Guide

Castor Wheels

Loading / Unloading Cycle Interruption System

Micro Switch Keypad Control Panel

Provision For Flash Socket Mounting

PRINT

Width 15 cm (6 inches),
Height 15 cm (6 inches)

PALLET

Width 11 cm (4.3 inches),
Height 23 cm (9 inches)

SCREEN

Width 28 cm (11 inches),
Height 38 cm (15 inches)

PRINTING
SPEED

1975 Pieces/h

Technical specifications

Configuration
PROMINI 8/1
PROMINI 8/2
PROMINI 8/3
PROMINI 10/4
Air @ 7 bar (102 psi)
235 l/min (8.3 cfm)
235 l/min (8.3 cfm)
235 l/min (8.3 cfm)
235 l/min (8.3 cfm)
Electrical Requirements
208–230 V, 1 ph, 39 A, 50/60 Hz, 7.05 kW (UL) 208–230 V, 1 ph, 39 A, 50 Hz, 7.05 kW (CE)
208–230 V, 1 ph, 39.5 A, 50/60 Hz, 7.15 kW (UL) 208–230 V, 1 ph, 39.5 A, 50 Hz, 7.15 kW (CE)
208–230 V, 1 ph, 40 A, 50/60 Hz, 7.25 kW (UL) 208–230 V, 1 ph, 40 A, 50 Hz, 7.25 kW (CE)
208–230 V, 1 ph, 53 A, 50/60 Hz, 9.6 kW
In-built Flash Cure Units
3
3
3
4
Diameter
128 cm (50.5")
128 cm (50.5")
128 cm (50.5")
146 cm (57.5")
Maximum Frame Size
28 × 38 cm (11" × 15")
28 × 38 cm (11" × 15")
28 × 38 cm (11" × 15")
28 × 38 cm (11" × 15")
Maximum Image Area
15 × 15 cm (6" × 6")
15 × 15 cm (6" × 6")
15 × 15 cm (6" × 6")
15 × 15 cm (6" × 6")
Machine Weight
262 kg (578 lb)
294 kg (648 lb)
326 kg (719 lb)
400 kg (882 lb)
Standard Pallet Size
11 × 23 cm (4.3" × 9")
11 × 23 cm (4.3" × 9")
11 × 23 cm (4.3" × 9")
11 × 23 cm (4.3" × 9")
Stations/Colors
8/1
8/2
8/3
10/4
DOWNLOAD PDF

Specifications

Galaxy Lunar (70 x 100 cm) 14/8

Galaxy Lunar (70 x 100 cm) 18/12

Galaxy Lunar (70 x 100 cm) 22/16

Galaxy Lunar (70 x 100 cm) 26/20

Galaxy Lunar (70 x 100 cm) 30/24

Galaxy Lunar (70 x 100 cm) 34/28

Air @ 7 Bar ( 102 psi)1

530l/min (18.7 cfm)

770 l/min (27.2 cfm)

1010 l/min (35.6 cfm)

1370 l/min (48.4 cfm)

1610 l/min (56.9 cfm)

1850 l/min (65.3 cfm)

Electrical Requirements2,3

380-415 V, 3 ph, 12 A, 50 Hz, 5.25 kW

380-415 V, 3 ph, 12 A, 50 Hz, 6.75 kW

380-415 V, 3 ph, 16.5 A, 50 Hz, 8.25 kW

380-415 V, 3 ph, 20 A, 50 Hz, 9.75 kW

380-415 V, 3 ph, 24.5 A, 50 Hz, 12.75 kW

380-415 V, 3 ph, 29 A, 50 Hz, 14.25 kW

Standard Image Size

70 x 100 cm (28" x 40")

70 x 100 cm (28" x 40")

70 x 100 cm (28" x 40")

70 x 100 cm (28" x 40")

70 x 100 cm (28" x 40")

70 x 100 cm (28" x 40")

Standard Pallet Size

76 x 122 cm (30” x 48”)

76 x 122 cm (30” x 48”)

76 x 122 cm (30” x 48”)

76 x 122 cm (30” x 48”)

76 x 122 cm (30” x 48”)

76 x 122 cm (30” x 48”)

Overall Size (L x W x H)

875 x 424 x 206 cm
(344.5" x 167" x 81")

1095 x 424 x 206 cm
(431" x 167" x 81")

1313 x 424 x 206 cm
(517" x 167" x 81")

1532 x 424 x 206 cm
(603" x 167" x 81")

1750 x 424 x 206 cm
(689" x 167" x 81")

1971 x 424 x 206 cm
(776" x 167" x 81")

Stations/Colors

14/8

18/12

22/16

26/20

30/24

34/28

Specifications

Galaxy Lunar (70 x 100 cm)  38/32

Galaxy Lunar (70 x 100 cm)  42/36

Galaxy Lunar (70 x 100 cm) 46/40

Galaxy Lunar (70 x 100 cm)  50/44

Galaxy Lunar (70 x 100 cm)  54/48

Galaxy Lunar (70 x 100 cm) 58/52

Air @ 7 Bar ( 102 psi)1

2090 l/min (73.8 cfm)

2330 l/min (82.3 cfm)

2570 l/min (90.8 cfm)

2810 l/min (99.3 cfm)

3050 l/min (107.8 cfm)

3290 l/min (116.3 cfm)

Electrical Requirements2,3

380-415 V, 3 ph, 33.5 A, 50 Hz, 15.75 kW

380-415 V, 3 ph, 38 A, 50 Hz, 17.25 kW

380-415 V, 3 ph, 42.5 A, 50 Hz, 18.75 kW

380-415 V, 3 ph, 47 A, 50 Hz, 20.25 kW

380-415 V, 3 ph, 51.5 A, 50 Hz, 21.75 kW

380-415 V, 3 ph, 56 A, 50 Hz, 23.25 kW

Standard Image Size

70 x 100 cm (28" x 40")

70 x 100 cm (28" x 40")

70 x 100 cm (28" x 40")

70 x 100 cm (28" x 40")

70 x 100 cm (28" x 40")

70 x 100 cm (28" x 40")

Standard Pallet Size

76 x 122 cm (30” x 48”)

76 x 122 cm (30” x 48”)

76 x 122 cm (30” x 48”)

76 x 122 cm (30” x 48”)

76 x 122 cm (30” x 48”)

76 x 122 cm (30” x 48”)

Standard Frame Size (OD)

86 x 135 cm (34" x 53")

86 x 135 cm (34" x 53")

86 x 135 cm (34" x 53")

86 x 135 cm (34" x 53")

86 x 135 cm (34" x 53")

86 x 135 cm (34" x 53")

Overall Size (L x W x H)

2189 x 424 x 206 cm
(862" x 167" x 81")

2408 x 424 x 206 cm
(948" x 167" x 81")

2626 x 424 x 206 cm
(1034" x 167" x 81")

2847 x 424 x 206 cm
(1121" x 167" x 81")

3066 x 424 x 206 cm
(1207" x 167" x 81")

3284 x 424 x 206 cm
(1293" x 167" x 81")

Stations/Colors

38/32

42/36

46/40

50/44

54/48

58/52

1Consumption @ 10 pieces/min; 7 bar input pressure & max image area

2General usage may vary, but will be significantly less than stated values

3Use Servo Stabilizers to safeguard the machine from Voltage Fluctuation out of the main supply.
